点击次数：

论文类型：期刊论文

发表时间：2015-02-01

发表刊物：JOURNAL OF MATERIALS SCIENCE & TECHNOLOGY

收录刊物：SCIE、EI、ISTIC、CSCD

卷号：31

期号：2

页面范围：217-222

ISSN号：1005-0302

关键字：Titanium aluminide; Steel; Dissimilar metal joining; Brazing; Mechanical property

摘要：Vacuum brazing of TiAl alloy to 40Cr steel sheets was conducted with newly developed CuTiNiZrV amorphous foils. It was found that a diffusion layer, filler metal and reaction layer existed in the brazed seam. The diffusion layer in the joint brazed with Cu43.75Ti37.5Ni6.25Zr6.25V6.25 (at.%) foil was flat and thin, containing Ti19Al6 and Ti2Cu intermetallic compounds; however, the diffusion layer brazed with Cu37.5Ti25Ni12.5Zr12.5V12.5 foil was uneven with bulges, consisting of essentially Ti-based solute solution. The foil with 12.5 at.% V showed inferior spreadability compared to that with 6.25 at.% V at brazing temperature. However, fracture happened along the diffusion layer with 6.25 at.% V foil due to the formation of brittle intermetallic phases, but the joints brazed with 12.5 at.% V foil failed through the TiAl substrate. These results show that designing amorphous alloy with less Ti and more V for brazing TiAl alloy to steel is appropriate.
