Flow regime identification for air valves failure evaluation in water pipelines using pressure data

点击次数:

论文类型:期刊论文

发表时间:2019-11-15

发表刊物:WATER RESEARCH

收录刊物:SCIE、EI、PubMed

卷号:165

页面范围:115002

ISSN号:0043-1354

关键字:Water transmission pipeline; Air valve; Flow regime identification; Support vector machine; Fault diagnosis

摘要:Air valve failure can cause air accumulation and result in a loss of carrying capacity, pipe vibration and even in some situations a catastrophic failure of water transmission pipelines. Air is most likely to accumulate in downward sloping pipes, leading to flow regime transition in these pipes. The flow regime identification can be used for fault diagnosis of air valves, but has received little attention in previous research. This paper develops a flow regime identification method that is based on support vector machines (SVMs) to evaluate the operational state of air valves in freshwater/potable pipelines using pressure signals. The laboratory experiments are set up to collect pressure data with respect to the four common flow regimes: bubbly flow, plug flow, blow-back flow and stratified flow. Two SVMs are constructed to identify bubbly and plug flows and validated based on the collected pressure data. The results demonstrate that pressure signals can be used for identifying flow regimes that represent the operational state (functioning or malfunctioning) of air valves. Among several signal features, Power Spectral Density and Short-Zero crossing Rate are found to be the best indictors to classify flow regimes by SVMs. The sampling rate and time of pressure signals have significant influence on the performance of SVM classification. With optimal SVM features and pressure sampling parameters the identification accuracies exceeded 93% in the test cases. The findings of this study show that the SVM flow regime identification is a promising methodology for fault diagnosis of air valve failure in water pipelines. (C) 2019 Elsevier Ltd. All rights reserved.
