论文类型：期刊论文

第一作者：Niu, Wenbin

通讯作者：Zhang, SF (reprint author), Dalian Univ Technol, State Key Lab Fine Chem, West Campus,2 Linggong Rd, Dalian 116024, Peoples R China.

合写作者：Zhang, Lele,Wang, Yunpeng,Zhang, Shufen

发表时间：2019-03-28

发表刊物：JOURNAL OF MATERIALS CHEMISTRY C

收录刊物：SCIE、EI

卷号：7

期号：12

页面范围：3463-3470

ISSN号：2050-7526

关键字：Adhesion; Atomic layer deposition; Automobile fabrics; Automotive industry; Electronics industry; Photonic crystals; Substrates; Surface reactions; Tape coatings, Continuous light; Mechanical robustness; One dimensional photonic crystal; Particle erosion; Periodic layers; Structural color; Substrate adhesion; Surface chemicals, Crystal atomic structure

摘要：High-performance one-dimensional photonic crystal coatings that sustain vivid structural colors under a variety of harsh mechanical conditions are fabricated using atomic layer deposition (ALD). By facilely controlling the thickness of the periodic layer, a series of photonic coatings with vivid structural colors ranging from purple, green, yellow, orange to red are obtained. By utilizing surface chemical adsorption and reaction characteristics of ALD process, these photonic crystal coatings exhibit high hardness, brightness, good substrate adhesion and strong mechanical robustness under cyclic tape peels (929 N m(-1) adhesion strength, 100 times) and rubbing (50 kPa load pressure, 100 times), respectively. More importantly, they can even withstand high-speed jet impact (at least 20 m s(-1), 30 min), particle erosion (200 rpm, 20 min), as well as continuous light irradiation. Given such impressive characteristics, these photonic crystal coatings would find promising applications in our daily life such as in consumer electronics, textiles, the automobile industry, and pigments.
