Accurate prediction approach of dynamic characteristics for a rotating thin walled annular plate considering the centrifugal stress requirement
点击次数:
论文类型:期刊论文
发表时间:2016-08-01
发表刊物:JOURNAL OF VIBROENGINEERING
收录刊物:SCIE
卷号:18
期号:5
页面范围:3104-3116
ISSN号:1392-8716
关键字:rotating; annular plates; scaling laws; centrifugal stress; sensitivity
摘要:In allusion to the problem that experimental results of similitude models of a rotating turbine disc predict dynamic characteristics of the prototype, the accurate design method of dynamic similitude models of a rotating thin walled annular plate is investigated by considering the centrifugal stress requirement. The vibration differential equation is employed to deduce geometrically complete scaling laws of dynamic frequency and centrifugal stress. In order to determine accurate distorted scaling laws of dynamic frequency, the sensitivity analysis and determination principle are used. For distorted scaling laws of centrifugal stress, the average approach of candidate distorted scaling laws is proposed, and its mathematical form is simple. Furthermore, the numerical validation indicates that distorted scaling laws can predict dynamic characteristics of the prototype and reflect the strength conditions or even failures of a prototype with good accuracy, and applicable intervals of the distorted scaling law are calculated. Finally, an acceptable procedure of the similitude design method of a rotating thin walled annular plate is provided, which guides to the design of test models considering centrifugal stress requirement.
