论文类型：期刊论文

发表时间：2019-01-01

发表刊物：IEEE ACCESS

收录刊物：SCIE、EI

卷号：7

页面范围：148208-148217

ISSN号：2169-3536

关键字：Chipless RFID; tag antennas; retro-radiator; RFID systems; van-atta array

摘要：Chipless RFID tag is a promising technique for future RFID systems due to its lowcost and high reliability. In this paper, three chipless RFID tags are designed based on retro-reflective structures, in order to increase the reading range and enhance the tag's robustness to the direction of the interrogating signals. The three tags include two linearly polarized tags with non-symmetric and symmetric filters and a circularly polarized tag. Before introducing the tag antennas, the design guidelines on how to arrange the filters for higher detection accuracy are provided based on standing wave analysis. Following the rules, retro-radiating tags with filters are designed. Since the E fields from the retro-radiating antennas add constructively in the direction of the incoming signal automatically, the reading distance is greatly increased compared with the conventional tags with orthogonally placed antennas. The tag with symmetric filters and arrangements can further enhance the detection robustness regardless of the reader's positions. Moreover, the circularly polarized tag is insensitive to the polarization of the incoming signals. The experimental results measured in the anechoic chamber show that the retro-radiator based tag can reach a reading distance of 60 cm, which is longer than most of the existing chipless tags. In the measurement, the proposed tag was well detected even when the reader antennas were not at the boresight.
