点击次数：

发表时间：2022-10-09

发表刊物：中国机械工程

所属单位：机械工程学院

卷号：20

期号：16

页面范围：1965-1969

ISSN号：1004-132X

摘要：There exists a great difference between the existing structural model of
   Permalloy magnetoelastic force transducers and the actual situation.For
   precise and quantitative analysis and research on the magnetoelastic
   effect of Permalloy,a representative model that regarded the Permalloy
   sensor as a two dimensional Permalloy plane unit was proposed,which
   reduced the difficulty for solving the problem.The ratio of stress to
   area was used as the appraisal and estimation criterion of the different
   structural model of the sensor.Finite element analysis software SSAP93
   was utilized to calculate and analyze the different structures of the
   studied sensor comparatively.The ultimate results of the finite element
   analysis determine the structure and size of the Permalloy
   magnetoelastic force transducer.

备注：新增回溯数据
