点击次数：

论文类型：期刊论文

发表时间：2021-01-10

发表刊物：IET SCIENCE MEASUREMENT & TECHNOLOGY

卷号：14

期号：8

页面范围：883-890

ISSN号：1751-8822

关键字：force sensors; dynamometers; force measurement; calibration; piezoelectric transducers; mathematical analysis; high-end tool condition monitoring; piezoelectric force sensors; piezoelectric dynamometer; six-degree-of-freedom force-thrust measurement stand; aerospace industry; mathematical model; calibration

摘要：Thrust testing units with a piezoelectric dynamometer have unique traits such as excessive stiffness, tremendous measurement accuracy, dynamic performance and no hysteresis. These are widely used in the applications requiring force/thrust measurements in the aerospace industry and high-end tool condition monitoring. The performance of these units is necessary to be evaluated. In this study, an improved layout of six-degree of freedom force/thrust measurement stand is proposed and analysed theoretically and experimentally. The measurement stand is a structural component to measure six components of force, such as axial force/thrust (F-X,F-Y, andF(Z)) and other components (M-X,M-Y, andM(Z)). Test stand consists of seven piezoelectric sensors in two sections. The front part consists of four piezoelectric force sensors, while the rear part consists of three sensors. The rear section is hexagonal, with three sensors mounted at 120 degrees. The measurement stand can measure the principal force/thrust up to 50,000 N. A mathematical model is derived for every sensor against forces in all directions. To calibrate the stand, a calibration platform is designed and fabricated. The calibration platform can generate a range of forces/moments. Calibration experiments verifies that the measurement stand is fairly functional to measure variety of forces/moments with high repeatability.
