点击次数：

论文类型：期刊论文

发表时间：2022-06-30

发表刊物：振动 测试与诊断

所属单位：建设工程学部

期号：2

页面范围：277-283

ISSN号：1004-6801

摘要：In order to get accurate and feasible seismic safety evaluation of a real dam, a self-developed miniature fiber bragg grating (FBG) strain sensor is used in this dam model experiment. By analyzing residual strain and peak strain produced by miniature FBG sensor in different magnitude, internal deformation and cracks of the dam model can be monitored, then seismic ability of the dam can be evaluated. The results of the experiment show that FBG sensor has high sensitivity and good anti-interference ability. It can monitor internal deformation and cracks of the dam model timely and accurately, then identify and warn structural damages. Through comparing concrete deformation and cracks produced by reinforced dam and unreinforced dam, it shows that steel bars embedded in the dam's weak position can restrain creation and development of cracks effectively and improve the anti-seismic capacity of dam significantly. The results of the experiment provide important basis for engineering design and the evaluation of dam anti-seismic ability.

备注：新增回溯数据
