Effects of phase matching pattern on pulse laser-arc hybrid welding process

点击次数:

论文类型:会议论文

发表时间:2014-07-26

收录刊物:EI

卷号:633-634

页面范围:634-637

关键字:Arc Plasma Compressions, Formation of Weld, Phase Matching, Weld Penetrations

摘要:This paper proposed a method on accurate phase matching control between the pulse laser and the AC TIG arc in real time, and a pulse laser-arc hybrid heat source phase matching control system is developed as well. With the utilization of this system in two typical matching cases that the pulse laser acts on the peak and the trough of the arc welding current waveform, effect regulations on weld formation, weld penetration depth and hybrid plasma shape are studied during welding on magnesium alloy AZ61. Results indicate that, when the pulse laser acting on the peak of arc welding current waveform, the weld formation is better than that of on the trough. However, when pulse laser act on the arc trough the weld penetration depth is deeper than that of on the peak. ? (2014) Trans Tech Publications, Switzerland.
