Indexed by:期刊论文

Date of Publication:2017-07-15

Journal:MATERIALS & DESIGN

Included Journals:SCIE、EI、Scopus

Volume:126

Page Number:135-140

ISSN No.:0264-1275

Key Words:3D printing; Composites; Anisotropic; Resistance

Abstract:A series of plastic items with anisotropic heat and resistance distribution were prepared by 3D printing. Conductive graphene doped polylactic acid (G-PLA) and pure PLA were used as raw materials. The programmed mixing printing method was adopted to construct these objects. The effects of the extrusion ratios of G-PLA and PLA, applied voltage and heat distribution on the printed items were investigated. We observed that the resistance of the printed items was controlled by the extrusion ratio during the 3D printing process. The distribution of the resistance is programmed by the slicing software and the single chip microcomputer in the 3D printer. The temperature of the printed test sheet varied from 20 to 90 degrees C according to the applied electronic current and voltage. Heterogeneous temperature regions were identified and showed isotropy. The temperature gradient field was constructed by designing and printing items with a quasi-continuously change resistance. The thermal signal was presented in the form of color information through a thermography device. As such, a simple message can be expressed and stored in this printed objects.
