论文类型：期刊论文

发表时间：2012-04-01

发表刊物：SENSORS AND ACTUATORS A-PHYSICAL

收录刊物：SCIE、EI、Scopus

卷号：176

页面范围：72-77

ISSN号：0924-4247

关键字：Temperature sensor; Gaseous thermal conduction; Microhotplate; CMOS-compatible

摘要：There are many different types of temperature sensors, including thermal resistor, thermocouple, thermal diode, etc. All the operational principles of them are based on the fact that some property of the sensor material is temperature-related. Based on the fact that the gaseous thermal conductivity of air is linear to the temperature from 250K to 500K, this paper proposes a new type of temperature sensor which employs the gas between the microhotplate and its substrate as the temperature sensing component. The temperature sensor consists of the CMOS-compatible tungsten microhotplate fabricated by surface micromachining technology as the heating component, the gas between the microhotplate and the substrate as the sensory material and the constant current circuit as the bias circuit. The heat of microhotplate can be dissipated by the gaseous thermal conduction which is dependent on the gas temperature. The measurement results show that the sensitivity of the sensor is 1 mV/degrees C and its linearity is 1.48% from -20 degrees C to 70 degrees C. The sensor with the inflatable sealed package with N-2 or inert gas can immerge in the gas or liquid atmosphere to measure the temperature. Crown Copyright (C) 2012 Published by Elsevier B.V. All rights reserved.
