The study on the rapidly-solidified Sn-0.7Cu lead-free solders and the interface reactions with Cu substrate

点击次数:

论文类型: 会议论文

发表时间: 2012-01-01

收录刊物: Scopus

页面范围: 361-365

摘要: The rapidly-solidified lead-free solders had lower melting point, narrower melting interval, better wettability and improved mechanical performance because of the fine, uniform and small segregation microstructure compared with the as-cast lead-free solders. In this study, a rapidly-solidified Sn-0.7Cu eutectic alloy was used as a sample for investigating the microstructure, wettability and the Cu6Sn5 IMCs and their growth behavior formed between the solders and Cu substrate. In addition, an as-cast Sn-0.7Cu solder was prepared as a reference. The results of the study showed that the microstructure composition was more uniform, the wettability was much better, the melting rate was much faster of the rapidly-solidified Sn-0.7Cu solders than the as-cast solders; the morphology of Cu6Sn5 grains formed between solders and substrate was different between rapidly-solidified and as-cast Sn-0.7Cu solders in short soldering duration; the rapidly-solidified Sn-0.7Cu solders were suitable for soldering with low temperature and short duration. ? 2012 IEEE.
