论文类型：期刊论文

发表时间：2017-12-01

发表刊物：PROCEEDINGS OF THE INSTITUTION OF MECHANICAL ENGINEERS PART C-JOURNAL OF MECHANICAL ENGINEERING SCIENCE

收录刊物：EI、SCIE

卷号：231

期号：23

页面范围：4479-4491

ISSN号：0954-4062

关键字：Thermal force measurement; thermal compensation; heat conduction; static calibration; force; heat coupling

摘要：A piezoelectric dynamometer can produce thermal forces because of temperature fluctuations, thus affecting measurement precision. To investigate the influence of the thermal force on the dynamometer, this article proposes a hypothesis of decreasing the conduction power and establishes the function of a thermal force over time in an ordinary dynamometer based on the heat conduction differential equation. A novel double-sensor thermal compensation dynamometer is designed, with static calibration in constant temperature and force/heat coupling experiments, to solve the problem of the thermal force. The experimental results indicate that the nonlinearity and repeatability of the double-sensor thermal compensation dynamometer are less than 1% full scale (FS) of the static calibration at a constant temperature; in the force/heat coupling experiments, at a heating rate of 0.4?/s to 110? with a loading force of 500N, the maximal output deviation is less than 1.06% (FS), realizing the unidirectional thermal force compensation of the structure. The double-sensor thermal compensation dynamometer can be utilized in sharp temperature fluctuations environment, like rocket engine forces measurement.
