论文类型：期刊论文

发表时间：2018-12-01

发表刊物：INTERNATIONAL JOURNAL OF HEAT AND MASS TRANSFER

收录刊物：SCIE、Scopus

卷号：127

页面范围：160-171

ISSN号：0017-9310

关键字：Condensation; Drops; Ethanol; Flow patterns; Free energy; Friction; Laminar flow; Microchannels; Mixtures; Pressure drop; Reynolds number; Transition flow; Water vapor, Annular flow pattern; Frictional pressure drops; Pressure drop model; Silicon microchannels; Surface free energy; Triangular microchannels; Two-phase pressure drops; Water-vapor mixtures, Two phase flow

摘要：Ethanol-water vapor mixtures condensation shows different flow patterns in microchannels due to the equivalent surface free energy differences. The transition point of streak flow pattern was introduced in the paper which was found closely related to the frictional pressure drop of ethanol-water vapor mixtures condensation flow in microchannels. Characteristics of two-phase pressure drop for ethanol-water vapor mixtures condensation flow in silicon microchannels of streak and smooth annular flow pattern were investigated. Four types of multi-port trapezoidal and triangular microchannels with hydraulic diameter in the range of 126-155 mu m were employed. The pressure drop was determined under steam mass flux between 259.2 and 504.8 kg m(-2) s(-1) when the inlet ethanol weight concentration varied from 1% to 60%. The experimental pressure drop results were compared with existing correlations of flow condensation. The transition point basing on the streak flow pattern of binary vapor condensation was proposed to replace the traditional Reynolds number criterion of the laminar flow state to turbulent flow state for the frictional factor and the C parameter for Kim and Mudawar's universal pressure drop model, which is in good agreement with the results the experiment results. (C) 2018 Elsevier Ltd. All rights reserved.
