论文类型：会议论文

发表时间：2008-01-01

收录刊物：EI、Scopus

卷号：6

期号：PARTS A AND B

页面范围：267-277

摘要：Welded, thick-walled piping intersections are widely used in many engineering applications including the offshore and nuclear power industries. These components are often fabricated by multipass welding which inevitably introduces undesirable residual stresses. In this contribution, weld-induced residual stresses in a thickwalled piping intersection were predicted using a validated, full three dimensional, sequentially coupled thermo-mechanical finite element simulation. The effect of cooling rate on the final residual stress state, especially at critical areas where the peak residual stresses are located, was then investigated by applying different convective heat transfer coefficients to the exposed piping intersection surfaces. It was found that the magnitudes and overall spatial distributions of residual stresses were very sensitive to cooling rate. Residual stresses on the outer surfaces of the component can be significantly reduced by external cooling. On the other hand, cooling the inner surfaces can dramatically convert residual stresses from tensile to compressive in these regions. The results and modeling technique presented in this contribution show that residual stress profiles in multipass welded complex geometries can be efficiently optimized through convenient cooling rate control. Copyright © 2008 by ASME.
