论文类型：会议论文

发表时间：2021-03-08

卷号：758

关键字：Stilling Basin; Hydraulic Jump; Hydraulic Characteristics; Roughened Bed; Sequent Depth; Energy Dissipation

摘要：The roughened-bed stilling basin, serving as one new type of energy dissipator, has been analyzed both theoretically and experimentally in the literature. This study deduces the calculation formula of the length of the curve C-0 between the flow-depth contraction section (i.e. h(c)) and the section just before the hydraulic jump (i.e. h(1)) when the same elevation is employed for both the bottom of roughened-bed stilling basin and the river-bed surface in the downstream. Further, by approximately assuming the equation of the resistance force exerted on the flow and caused by the bed roughness, this study obtains the expression of the ratio between the flow depth before the hydraulic jump and that behind the hydraulic jump, namely h(1)/h(2). With the aid of the experimental results in the existing literature, it can be concluded that, when compared with the traditional smooth-bed hydraulic jump, the sequent depth and the length of the rolling hydraulic jump can be reduced by about 20 similar to 30% and 20 similar to 50%, respectively, in the condition of the chopping roughness riverbed. Additionally, by combining with the hydraulic model tests, this study indicates that adding the bed-roughness can eliminate the secondary hydraulic jump, improve the flow regime and (under the circumstance of the sill-roughness stilling basin) decrease the length of the stilling basin up to about 40%similar to 50%.
