点击次数：

发表时间：2015-01-01

发表刊物：计算力学学报

期号：2

页面范围：220-224,231

ISSN号：1007-4708

摘要：As to the increasing requirements for computational scale and expanding application areas of fi‐nite element method ,an open general visual system is designed and implemented .The visual system is developed for large scale finite element computation visualization with over millions of or tens of millions of nodes .In the architecture design , the stream architecture is introduced .T his architecture has the characteristics of high efficiency for both computation and communication ,w hich meets the needs of large scale data processing .In the software implementation ,factory method pattern and plug‐in technology are employed w hich improve the expansibility and flexibility of the system .Several modules ,like finite element model module ,filter module and render module ,are designed and implemented .In the large scale data visualization ,using VBO and partial load ,the large scale model can be displayed in real time .Several model examples are presented to show the feasibility and superiority of the system .

备注：新增回溯数据
