论文类型：期刊论文

发表时间：2019-05-02

发表刊物：ENERGIES

收录刊物：SCIE、EI

卷号：12

期号：10

ISSN号：1996-1073

关键字：non-embedded; pressure core; P-wave detection; hydrate saturation

摘要：An apparatus for the analysis of pressure cores containing gas hydrates at in situ pressures was designed, and a series of experiments to determine the compressional wave response of hydrate-bearing sands were performed systematically in the laboratory. Considering the difficulties encountered in performing valid laboratory tests and in recovering intact hydrate bearing sediment samples, the laboratory approach enabled closer study than the marine environment due to sample recovery problems. The apparatus was designed to achieve in situ hydrate formation in bearing sediments and synchronous ultrasonic detection. The P-wave velocity measurements enabled quick and successive ultrasonic analysis of pressure cores. The factors influencing P-wave velocity (V-p), including hydrate saturation and formation methodology, were investigated. By controlling the initial water saturation and gas pressure, we conducted separate experiments for different hydrate saturation values ranging from 2% to 60%. The measured P-wave velocity varied from less than 1700 m/s to more than 3100 m/s in this saturation range. The hydrate saturation can be successfully predicted by a linear fitting of the attenuation (Q(-1)) to the hydrate saturation. This approach provided a new method for acoustic measurement of the hydrate saturation when the arrival time of the first wave cannot be directly distinguished. Our results demonstrated that the specially designed non-embedded ultrasonic detection apparatus could determine the hydrate saturation and occurrence patterns in pressure cores, which could assist further hydrate resource exploration and detailed core analyses.
