Impedance Matching for 13.56 MHz NFC Antennas without VNA
点击次数：
论文类型：会议论文
发表时间：2016-01-01
收录刊物：CPCI-S、CPCI-SSH
页面范围：308-311
关键字：Impedance matching; Near field communication; Antenna; Vector Network Analyzer
摘要：This paper introduces a method of impedance matching for 13.56 MHz NFC antennas without Vector Network Analyzer (VNA). A LCR meter is used to measure resistance and inductance of antennas instead. A three components match is adopted to realize 50-Omega antenna impedance. Both antenna on board and external antenna are designed with rectangular planar spiral copper. They are tested and compared with each other. The results show that two antennas can work well. External antenna has better performance than one on board.
