论文类型：期刊论文

发表时间：2006-06-01

发表刊物：5th International Forum on Advanced Material Science and Technology

收录刊物：SCIE、EI、CPCI-S、ISTIC、Scopus

卷号：16

期号：,1

页面范围：S47-S51

ISSN号：1003-6326

关键字：electromagnetic elimination; non-metallic inclusions; elimination time; elimination efficiency

摘要：In order to find the ways to improve the elimination efficiency with high frequency magnetic field, a mathematical model of electromagnetic elimination (EME) in the tubule with high frequency magnetic field was set up. The calculated results show that by ignoring the flow of molten metal, when the surface magnetic induction intensity of the metal (B-0) is 0.03 T and the diameter of the tubule is 8 mm, the non-metallic inclusions with 30 mu m diameter can be wiped off in 7 s from the center of the molten aluminum, whereas the elimination time of the 5 gm non-metallic inclusions is more than 240 s. When B0 is 0.03 T, the diameter of the tubule is 8 mm and elimination time is more than 30 s, the elimination efficiency of 5 mu m, 10 mu m and 30 mu m non-metallic inclusions is about 60%, 90% and 100%, respectively, the elimination efficiency increases with the decreasing diameter of the tubule. It can be concluded that increasing the magnetic induction intensity or decreasing the diameter of the tubule can decrease the elimination time and improve the elimination efficiency in EME with high frequency magnetic field.
