论文类型：期刊论文

发表时间：2021-01-10

发表刊物：IEEE ANTENNAS AND WIRELESS PROPAGATION LETTERS

卷号：19

期号：10

页面范围：1664-1668

ISSN号：1536-1225

关键字：Bandwidth; Antenna feeds; Inductors; Slot antennas; Dipole antennas; Substrates; Differential feeding; dual modes; dual-polarized antenna; wideband

摘要：A wideband differentially fed dual-polarized dual-mode antenna is presented in this letter. Four slots are placed a square shape to construct the slot loop antenna, and the outer ground of the slot loop is bended to achieve a compact size. A simple out-of-phase power splitter with a wide bandwidth and accurate 180 degrees phase difference is integrated with the radiator to feed the slot loop. The 1 and 2 lambda modes of the slot loop antenna are excited with the differential feeding for a wide impedance bandwidth (IMBW). By loading the distributed inductors at the ends of each slot, a radiator size of 106 x 106 mm(2) is obtained to cover LTE700/GSM850/GSM900 bands. Measured results show that the antenna has the IMBWs of 0.63-1.09 GHz (0.46 GHz, 53.5%) and 0.63-1.08 GHz (0.45 GHz, 52.6%) for the two input ports, isolation of more than 31.5 dB, and stable gain of around 7.15 +/- 0.35 dBi for Port 1.
