OPTIMAL DESIGN AND EVALUATION OF A RING-DIE GRANULATOR FOR STRAWS
- 点击次数：
- 论文类型：期刊论文
- 发表时间：2012-02-01
- 发表刊物：BIORESOURCES
- 收录刊物：SCIE、EI、Scopus
- 文献类型：J
- 卷号：7
- 期号：1
- 页面范围：489-503
- ISSN号：1930-2126
- 关键字：Straw; Briquetting rate; Granularity; Moisture ratio; Length-diameter
ratio of die hole
- 摘要：This research provides an optimal design of structural parameters for ring-die granulators used in the cool briquetting process. Experimental research on the briquetting rate of pellets was carried out for three kinds of crop straws with different granularities, moisture ratios, and length-diameter ratios of the die hole. Results showed that: when the swoop angle beta was 45 degrees and the diameter ratio of roller to die was equal to 0.585, the equipment would have higher productivity and lower die-roller contact strength, yielding a good comprehensive briquetting effect; when the granularity was 4 mm, the moisture ratio was 16% and the length-diameter ratio was 5.2, the equipment would ensure a higher briquetting rate of pellets and the lowest power consumption per ton of material, yielding the best briquetting effect. This provides references for structural design and process parameters selection of ring-die granulators.
