论文类型：会议论文

发表时间：2006-11-22

收录刊物：EI、CPCI-S

卷号：353-358

期号：PART 2

页面范围：961-+

关键字：acoustic emission (AE); rock and concrete; relative notch depth; failure process; RFPA(3D); numerical simulation

摘要：Based on physical model of three-point-bending test, the AE characteristics of three-point-bending beams with different relative notch depth during the entire loading period was simulated by using RFPA(3D) (realistic failure process analysis) code. Simulation results show that the relative notch depth affects the AE characteristics significantly. With increasing relative notch depth, the occurrence of AE events decreases remarkably. The stress distribution figures, elastic modulus photo and AE relative energy time-space distribution figures as well as an analysis on the failure process are also provided. Based on the analysis of simulation results, it is concluded that the heterogeneity of rock and concrete has great influence on the crack propagation path, which leads the crack propagation path becoming curvilinear.
