Recurrence quantitative analysis for porosity characterization of CFRP with complex void morphology

点击次数:

论文类型:期刊论文

发表时间:2019-12-01

发表刊物:COMPOSITE STRUCTURES

收录刊物:EI、SCIE

卷号:229

ISSN号:0263-8223

关键字:Carbon Fibre Reinforced Plastics (CFRP); Porosity; Ultrasonic backscattered signal; Recurrence quantitative analysis (RQA); Real Morphology Void Model (RMVM); Void morphology

摘要:The porosity characterization of Carbon Fibre Reinforced Plastics (CFRP) by ultrasonic attenuation measurement is restricted when the back-wall echoes are weak or absent at high porosity, and the estimation accuracy is decreased with increment of porosity due to complex void morphology. In this paper, Real Morphology Void Models (RMVMs) with different porosity were established to simulate the interaction between ultrasonic waves and voids with complex morphology. Subsequently, Recurrence Quantification Analysis (RQA) was introduced to process ultrasonic backscattered signals generated by voids so as to present Recurrence Plots (RPs) for porosity characterization. Recurrence Rate (RR) was selected as RQA variable to quantitatively analyze RPs, avoiding the determination of additional parameters. The correlation between porosity P and RR was revealed by simulation for the first time, and verified by experiments with CFRP laminates having porosity of 0.8%-4.2%. The complex and random void morphology induced the non-mapping relationship between P and RR, influencing estimation accuracy of porosity. The normalized results indicated that porosity characterization with RR was less affected by void morphology for P > 1.97% in comparison with ultrasonic attenuation measurement. It is concluded that RQA is valuable for porosity characterization of CFRP with high porosity and strong attenuation.
