论文名称：Heat transfer characteristics of in-tube steam condensation process under stratified flow
论文类型：期刊论文
发表刊物：INTERNATIONAL JOURNAL OF HEAT AND MASS TRANSFER
收录刊物：EI、SCIE
卷号：145
ISSN号：0017-9310
关键字：Falling film evaporator; In-tube condensation; Effective tube length; Partition map
摘要：For stratified flow condensation process, the heat transfer mechanisms in the film condensation zone above the vapour-liquid interface and the condensate zone below the interface shows significant differences. In the multi-effect evaporation device, due to the high sensitivity of the thermal performance to the variation of the heat transfer parameters, the heat transfer parameters distributions in the film condensation zone and in the condensate zone are worth exploring. In this paper, a validated distributed parameter model was established to simulate the heat transfer and flow process in a single tube of the falling film evaporator. The variation of the heat flux in the condensate zone was presented under various operating conditions. The concept of the effective tube length and the partition map of the in-tube condensation heat transfer process were proposed for the better understanding of the flow and heat transfer process. Results show that the heat transfer in the condensate zone to the total heat transfer can accounts for more than 10% of the total heat transfer, thus cannot be neglected. For the design of falling film evaporator, the condensation heat transfer process in the tube should be located in the high-efficiency heat transfer section. The steam mass flow rate, heat transfer temperature difference and the length of the heat transfer tube should matched to each other to guarantee the condensation heat transfer process be located in the high-efficiency heat transfer zone. (C) 2019 The Authors. Published by Elsevier Ltd.
发表时间：2019-12-01
