论文类型：期刊论文

发表时间：2011-04-01

发表刊物：Journal of Donghua University (English Edition)

收录刊物：EI、Scopus

卷号：28

期号：2

页面范围：124-127

ISSN号：16725220

摘要：The attitude of the shield tunneling machine ( or "shield" for short) during tunneling is important to tunnel excavation and construction quality, which results from a combination of jack thrust, ground displacement around the shield, and ground mechanics parameters, etc. A shield attitude model involving elements above was proposed. In this model, ground displacement was taken to calculate the load around the shield. Ground mechanics parameters were involved. Based on the shield load model, the needed jack thrust for shield desired attitude was derived. The proposed method is validated using engineering data, and lays reliable foundation for shield attitude control.
