论文类型： 期刊论文

发表时间： 2020-06-01

发表刊物： MATERIALS TODAY COMMUNICATIONS

收录刊物： EI、SCIE

卷号： 23

ISSN号： 2352-4928

关键字： 3D packaging; Single crystal; Prism-type; Temperature gradient; Intermetallic alloys and compounds; Electronic materials

摘要： The morphology evolution of Cu6Sn5 grains in (001)Cu/Sn/Cu and (011)Cu/Sn/Cu micro solder joints reflowing with and without a temperature gradient was studied. In the as-soldered state, regular and perpendicular prism-type Cu6Sn5 grains formed on (001)Cu substrate, while a mixture of stubby prism-type and scallop-type Cu6Sn5 grains formed on (011)Cu substrate. The prism-type morphology gradually transferred into scallop-type after isothermally reflowed at 270 degrees C for 10 min. However, with a temperature gradient, the initial perpendicular small prismatic Cu6Sn5 grains on (001)Cu substrate and mixed-type Cu6Sn5 grains on (011)Cu continued to grow into large prism-type. All the prism-type Cu6Sn5 grains grew along same direction after long time reflow under temperature gradient due to the merging of adjacent Cu6Sn5 grain pair.
